Inventec B800 - Advanced

BIOS Setup
60
4.1.2 Advanced
Aptio Setup Utility –Copyright © 2010 American Megatrends, Inc.
Main Advanced Boot Security Save&Exit Event Logs Server Mgmt
Intel(R) VT-d
Restore AC Power Loss
▶ Trusted Computing
▶ CPU Configuration
▶ Runtime Error Logging
▶ SATA Configuration
▶ USB Configuration
▶ Runtime Memory Hole Setting
▶ Info Report Configuration
▶ Super IO Configuration
▶ PCI Express Settings
▶ ME Subsystem
▶ Memory Configuration
▶ Onboard Device Configuration
▶ Serial Port Console Redirection
iSCSI
[Disabled]
[Power off]
→←: Select Screen
↑↓: Select Item
Enter: Select
+/-: Change Opt.
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC: Exit
Version 2.02.1205. Copyright © 2010 American Megatrends, Inc.
Menu Fields
Settings
Comments
Advanced
Restore AC power Loss
[Pwer off]
[Power on]
[Last state]
Specify what state to go to when power is
re-applied after a power failure (G3 state).
Inter(R) VT-d
[Disabled]
[Enabled]
Enabled/Disabled Intel(R) Virtualization Technology for
Directed I/O.
