Hardware Operations
17
2.4.3 To remove the processor
Unlock the load lever and lift it up.
Open the load plate.
Figure 2-4 Opening the Load Plate
Lift the processor out of the socket.
Figure 2-5 Lifting the Processor out of the Socket
