Pin
Signal Name
17
NIC1_MDI_3_DN
18
NIC1_MDI_3_DP
19
P1VB_STBY
20
Ground
21
NIC2_1000M_ORG_N
22
NIC2_100M_GRN_N
23
NIC2_ACT_N
24
NIC2_LINK_N
25
NIC1_1000M_ORG_N
26
NIC1_100M_ORG_N
27
NIC1_ACT_N
28
NIC1_LINK_N
29
Ground
30
Ground
31
Ground
32
Ground
