Invivo UroNav - Foot Pedal Switch

6. EM Tracker connectors x 4 (arrows on the cable connector face
forward)
7. Field Generator cable connector (red dot on the cable connector
faces forward)
8. USB: 3-pedal foot switch, supplied with UroNav system, and end-user
supplied portable USB memory drives
9. Power ON button
Front Panel Connections
Foot Pedal Switch
7
6
9
8
7
6
8
9
.
.
Page 2
Section 1.1: Connections to Peripheral Equipment (continued)
