Goodrive300-19 series open loop vector inverter special for hosit Function parameters
-114-
Function
code
Name
Detailed instruction of parameters
Default
value
Modify
switching-off
current
succeeds (output current and torque respectively
reach the standard of the set value). Setting ranges:
P19.12: 0.00~20.00Hz
P19.13: 0.0~200.0% (motor rated current)
P19.14: 0.0~200.0% (motor rated torque)
P19.14
FWD
switching-off
torque
0.0%
◎
P19.15
REV
switching-off
frequency
The three parameters are switching-off conditions in
reverse rotation. The inverter will send switching-off
signal after the running frequency exceeds
switching-off frequency and torque verification
succeeds (output current and torque respectively
reach the standard of the set value). Setting ranges:
P19.15: 0.00~20.00Hz
P19.16: 0.0~200.0% (motor rated current)
P19.17: 0.0~200.0% (motor rated torque)
2.00Hz
◎
P19.16
REV
switching-off
current
0.0%
◎
P19.17
REV
switching-off
torque
0.0%
◎
P19.18
Switching-off
hold
frequency
Refer to brake control function in Chapter 7 for
detailed instruction of parameters
Setting range: 0.00~20.00Hz
3.00Hz
◎
P19.19
Switching-off
delay time
Refer to brake control function in Chapter 7 for
detailed instruction of parameters
Setting range: 0.00~5.000S
0.000s
◎
P19.20
FWD
switching-on
frequency
Refer to brake control function in Chapter 7 for
detailed instruction of parameters
Setting range: 0.00~20.00Hz
3.00Hz
◎
P19.21
REV
switching-on
frequency
Refer to brake control function in Chapter 7 for
detailed instruction of parameters
Setting range: 0.00~20.00Hz
3.00Hz
◎
P19.22
Switching-on
hold
frequency
Refer to brake control function in Chapter 7 for
detailed instruction of parameters
Setting range: P01.15~50.00Hz
3.00Hz
◎
P19.23
Switching-on
delay time
Refer to brake control function in Chapter 7 for
detailed instruction of parameters
Setting range: 0.00~5.000s
0.000s
◎
P19.24
Brake
Refer to brake control function in Chapter 7 for
1.000s
◎
