Goodrive300-19 series open loop vector inverter special for hosit Basic operation instruction
-152-
0: Setting is valid
1: Valid during running, clear after stop
2: Valid during running, clear after receiving the stop
command
P08.45
UP terminals
frequency
changing ratio
0.01~50.00Hz/s
0.50Hz/s
P08.46
DOWN
terminals
frequency
changing ratio
0.01~50.00Hz/s
0.50Hz/s
P17.00
Setting
frequency
0.00Hz~P00.03 (Max. output frequency)
0.00Hz
P17.02
Ramp
reference
frequency
0.00Hz~P00.03 (Max. output frequency)
0.00Hz
P17.14
Digital
adjustment
0.00Hz~P00.03
0.00Hz
7.9 Analog input
Goodrive300-19 series inverters have three analog input terminals and 1 high-speed pulse input
terminal (of which, AI1 and AI2 are 0~10V/0~20mA and Al can select voltage input or current input by
J3, AI2 can select voltage input or current input by J4 and AI3 is for -10~10V ) as the standard
configuration. The inputs can be filtered and the maximum and minimum values can be adjusted.
