INVT Goodrive300-19 Series User Manual

Goodrive300-19 series open loop vector inverter special for hosit Product overview
-13-
Note:
1. The inverters of 380V (≥75kW) supports external DC reactors and external braking units, but
it is necessary to remove the copper tag between P1 and (+) before connecting. DC reactors
and external braking units are optional.
2. The inverters of 380V (≤55kW) supports external braking resistors which are optional.
3. Before connecting the braking resistor cable, remove the yellow labels of PB, (+), and (-)
from the terminal blocks. Otherwise, poor connection may occur.
3.3 Product specification
Function
Specification
Power
input
Input voltage (V)
AC 3PH 380V(-15%)~440V(+10%)
Input current (A)
Refer to the rated value
Input frequency (Hz)
50Hz or 60Hz
Allowed range: 47~63Hz
Power
output
Output voltage (V)
0~input voltage
Output current (A)
Refer to the rated value
Output power (kW)
Refer to the rated value
Output frequency (Hz)
0~400Hz
Technical
control
feature
Control mode
SVPWM, SVC
Motor type
Asynchronous motor
Adjustable-speed ratio
1: 200 (SVC)
Speed control
accuracy
±0.2% (SVC)
Speed fluctuation
± 0.3% (SVC)
Torque response
<20ms (SVC)
Torque control
accuracy
10% (SVC)
Starting torque
0.25Hz/150% (SVC)
Overload capability
150% of rated current: 1 minute
180% of rated current: 10 seconds
200% of rated current: 1 second
Running
control
feature
Frequency setting
method
Digital setting, analog setting, pulse frequency setting,
multi-step speed running setting, Modbus
communication setting.
Switch between the combination and the set channel.
