INVT Goodrive300-19 Series User Manual

Goodrive300-19 series open loop vector inverter special for hosit Product overview
-14-
Function
Specification
Auto-adjustment of the
voltage
Keep constant voltage automatically when the grid
voltage transients
Fault protection
Provide more than 30 fault protection functions:
overcurrent, overvoltage, undervoltage, overheating,
phase loss and overload, etc.
Special function
Brake function special for hoists, joystick zero
detection, torque verification, brake contactor control,
short circuit braking
Operation mode
special for hoists
Joystick mode, remote control mode, electromotion
potentiometer mode, hierarchical joystick reference
mode, hierarchical radio reference mode
Restart after rotating
speed tracking
Smooth starting of the rotating motor
Note: ≥4kW, the function is available.
Peripheral
interface
Terminal analog input
resolution
≤ 20mV
Terminal switch input
resolution
≤ 2ms
Analog input
2 (AI1, AI2) 0~10V/0~20mA and 1 (AI3) -10~10V
Analog output
2 (AO1, AO2) 0~10V/0~20mA
Digital input
8 common inputs, the Max. frequency: 1kHz, internal
impedance: 3.3kΩ;
1 high-speed input, the Max. frequency: 50kHz
Digital output
1 high speed pulse output, the Max. frequency: 50kHz;
1 Y terminal open collector output
Relay output
2 programmable relay outputs
RO1A NO, RO1B NC, RO1C common terminal
RO2A NO, RO2B NC, RO2C common terminal
Contact capacity: 3A/AC250V, 1A/DC30V
Others
Mountable method
Wall, flange and floor mounting
Temperature of the
running environment
-10~50°C , derate above 40°C . If temperature is above
40℃, derate 1% for every additional 1℃.
Average non-fault time
2 years (25°C ambient temperature)
Protective degree
IP20
Cooling
Forced air cooling
