INVT Goodrive300-19 Series - Hoist Operating Mode

Goodrive300-19 series open loop vector inverter special for hosit Basic operation instruction
-181-
Function
code
Name
Detailed instruction of parameters
Default
value
P05.06
S6 terminal function selection
0
P05.07
S7 terminal function selection
0
P05.08
S8 terminal function selection
0
P05.09
HDI terminal function
selection
0
P05.10
Polarity selection of input
terminals
0x000~0x1FF
0x000
P05.11
ON-OFF filter time
0.000~1.000s
0.010s
P19.00
Operating mode selection
0: Common mode
1: Joystick mode
2: Remote control mode
3: Hierarchical joystick mode
4: Hierarchical remote control mode
5: Electromotion potentiometer mode
0
P19.06
Hierarchical multi-step speed
reference 0
0.0~100.0%
0.0%
P19.07
Hierarchical multi-step speed
reference 1
0.0~100.0%
0.0%
P19.08
Hierarchical multi-step speed
reference 2
0.0~100.0%
0.0%
P19.09
Hierarchical multi-step speed
reference 3
0.0~100.0%
0.0%
P19.10
Hierarchical multi-step speed
reference 4
0.0~100.0%
0.0%
P17.38
Current step of hierarchical
multi-step speed
0~6
0
7.16 Hoist operating mode
The hoist operating mode is a convenient mode set according to industrial applications and customer
demands, mainly including:
0: Common mode
1: Joystick mode
2: Remote control mode
