INVT Goodrive300-19 Series User Manual

Goodrive300-19 series open loop vector inverter special for hosit Basic operation instruction
-182-
3: Hierarchical joystick mode
4: Hierarchical remote control mode
5: Electromotion potentiometer mode
Users can select according to the actual conditions. The standard wiring diagrams and function code
settings corresponding to the modes are described as follows. It only needs to set P19.00 to meet the
requirements of basic applications. The modes cannot satisfy all applications, so users can select an
approximate mode and fine-tune the parameters.
7.16.1 Common mode
The wiring diagram of common mode is as follows:
GD300-19 inverter
FWD running
S1
Frequency reference
Keypad
REV running
S2
Fault reset
S3
RO1
Motor in running
RO2
Fault output
AO1
Running
frequency
AO2
Set frequency
The mode is used when I/O signal setting and function in default. Set P19.00 to “0: Common mode”.
The parameters of common mode are as follows:
Function
code
Name
Function
selection
Function instruction
P00.01
Running command channel
1
Terminal running command
channel (LED flickering)
P00.06
A frequency command
0
Keypad setting
P05.01
S1 terminal function selection
1
Forward rotation operation (FWD)
P05.02
S2 terminal function selection
2
Reverse rotation operation (REV)
P05.03
S3 terminal function selection
7
Fault reset (RET)
P06.03
Relay RO1 output
1
Motor in running
P06.04
Relay RO2 output
5
Fault output
P06.14
AO1 output
0
Running frequency
P06.15
AO2 output
1
Set frequency
