Goodrive300-19 series open loop vector inverter special for hosit Product overview
-16-
3.6 Rated specifications
3.6.1 The inverters of AC 3PH 380V(-15%)~440V(+10%)
Model
Constant torque
Rated output power
(kW)
Rated input current
(A)
Rated output
current (A)
GD300-19-1R5G-4
1.5
5.0
3.7
GD300-19-2R2G-4
2.2
5.8
5
GD300-19-004G-4
4
13.5
9.5
GD300-19-5R5G-4
5.5
19.5
14
GD300-19-7R5G-4
7.5
25
18.5
GD300-19-011G-4
11
32
25
GD300-19-015G-4
15
40
32
GD300-19-018G-4
18.5
47
38
GD300-19-022G-4
22
56
45
GD300-19-030G-4
30
70
60
GD300-19-037G-4
37
80
75
GD300-19-045G-4
45
94
92
GD300-19-055G-4
55
128
115
GD300-19-075G-4
75
160
150
GD300-19-090G-4
90
190
180
GD300-19-110G-4
110
225
215
GD300-19-132G-4
132
265
260
GD300-19-160G-4
160
310
305
GD300-19-185G-4
185
345
340
GD300-19-200G-4
200
385
380
GD300-19-220G-4
220
430
425
GD300-19-250G-4
250
485
480
GD300-19-280G-4
280
545
530
GD300-19-315G-4
315
610
600
Note:
1. The input current of inverters 1.5~315kW is detected when the input voltage is 380V and
there is no DC reactors and input/output reactors.
2. The rated output current is defined when the output voltage is 380V.
