INVT Goodrive300-19 Series User Manual

Goodrive300-19 series open loop vector inverter special for hosit Basic operation instruction
-142-
motor 2
P12.05
Rated current
of
asynchronous
motor 2
0.8~6000.0A
Depend
on model
P12.06
Stator resistor
of
asynchronous
motor 2
0.001~65.535Ω
Depend
on model
P12.07
Rotor resistor
of
asynchronous
motor 2
0.001~65.535Ω
Depend
on model
P12.08
Leakage
inductance of
asynchronous
motor 2
0.1~6553.5mH
Depend
on model
P12.09
Mutual
inductance of
asynchronous
motor 2
0.1~6553.5mH
Depend
on model
P12.10
Non-load
current of
asynchronous
motor 2
0.1~6553.5A
Depend
on model
7.7 Start-up and stop control
The start-up and stop control of the inverter includes three states: start after the running command
during normal powering on, start after the restarting function becomes valid during normal powering
on and start after the automatic fault reset. Below is the detailed instruction for three startings.
There are three starting methods for the inverter: start from the starting frequency directly, start after
the AC braking and start after the rotation speed tracking. The user can select according to different
situations to meet their needs.
For the load with big inertia, especially in the cases where the reverse rotation may occur, it is better
to select starting after DC braking and then starting after rotation speed tracking.
1. The starting logic figure of starting after the running command during the normal powering on
