INVT Goodrive300-19 Series User Manual

Goodrive300-19 series open loop vector inverter special for hosit Technical data
-231-
Frequency resolution
0.01Hz
Current
Refer to Ratings
Power limit
1.5·PN
Field weakening
point
10...400Hz
Carrier frequency
4, 8, 12 or 15kHz
A.4.1 EMC compatibility and motor cable length
To comply with the European EMC Directive (2004/108/EC), use the following maximum motor cable
lengths for 4kHz switching frequency.
All frame sizes (with external EMC filter)
Maximum motor cable length (m)
Second environment (category C3)
30
First environment (category C2)
30
The maximum motor cable length is determined by the drive’s operational factors. Contact the local
representative for the exact maximum lengths when using external EMC filters.
For the instruction of the second environment (category C3) and first environment (category C2),
please refer to EMC regulations.
A.5 Applicable standards
The inverter complies with the following standards:
EN/ISO 13849-1:2008
Safety of machinery-Safety related parts of control systems. Part
1: General principles for design
IEC/EN 60204-1:2006
Safety of machinery. Electrical equipment of machines. Part 1:
General requirements
IEC/EN 62061:2005
Safety of machinery–Functional safety of safety-Related
electrical, electronic and programmable electronic control
systems
IEC/EN 61800-3:2004
Adjustable speed electrical power drive systems. Part 3: EMC
requirements and specific test methods
IEC/EN 61800-5-1:2007
Adjustable speed electrical power drive systems–Part 5-1:
Safety requirements–Electrical, thermal and energy
IEC/EN 61800-5-2:2007
Adjustable speed electrical power drive systems–Part 5-2:
Safety requirements–Functional
A.5.1 CE marking
The CE mark is attached to the drive to verify that the drive follows the provisions of the European
Low Voltage and EMC Directives.
