INVT Goodrive300-19 Series User Manual

Goodrive300-19 series open loop vector inverter special for hosit Peripherial options and parts
-245-
C.5.1 AC 3PH 380V(-15%)~440V(+10%)
Inverter model
Fuse (A)
Breaker (A)
Rated working current of
the contactor (A)
GD300-19-1R5G-4
15
16
10
GD300-19-2R2G-4
17.4
16
10
GD300-19-004G-4
30
25
16
GD300-19-5R5G-4
45
25
16
GD300-19-7R5G-4
60
40
25
GD300-19-011G-4
78
63
32
GD300-19-015G-4
105
63
50
GD300-19-018G-4
114
100
63
GD300-19-022G-4
138
100
80
GD300-19-030G-4
186
125
95
GD300-19-037G-4
228
160
120
GD300-19-045G-4
270
200
135
GD300-19-055G-4
315
200
170
GD300-19-075G-4
420
250
230
GD300-19-090G-4
480
315
280
GD300-19-110G-4
630
400
315
GD300-19-132G-4
720
400
380
GD300-19-160G-4
870
630
450
GD300-19-185G-4
1110
630
580
GD300-19-200G-4
1110
630
580
GD300-19-220G-4
1230
800
630
GD300-19-250G-4
1380
800
700
GD300-19-280G-4
1500
1000
780
GD300-19-315G-4
1740
1200
900
C.6 Reactors
Transient high current in the input power circuit may cause damage to the rectifying components. It is
appropriate to use AC reactor in the input side for the avoidance of high-voltage input of the power
supply and improvement of the power factors.
If the distance between the inverter and the motor is longer than 50m, frequent overcurrent protection
may occur to the inverter because of high leakage current caused by parasitic capacitance effects
from the long cables to the ground. In order to avoid the damage of the motor insulation, it is
