INVT Goodrive300-19 Series User Manual

Goodrive300-19 series open loop vector inverter special for hosit Basic operation instruction
-172-
36: Ready for switching on
37: Motor 2 in operation
38~40: Reserved
P06.05
Polarity of
output
terminals
00~0F
00
P06.06
Y switch-on
delay time
0.000~50.000s
0.000s
P06.07
Y switch-off
delay time
0.000~50.000s
0.000s
P06.08
HDO switch-on
delay time
0.000~50.000s (only valid when P06.00=1)
0.000s
P06.09
HDO switch-off
delay time
0.000~50.000s (only valid when P06.00=1)
0.000s
P06.10
RO1 switch-on
delay time
0.000~50.000s
0.000s
P06.11
RO1 switch-off
delay time
0.000~50.000s
0.000s
P06.12
RO2 switch-on
delay time
0.000~50.000s
0.000s
P06.13
RO2 switch-off
delay time
0.000~50.000s
0.000s
P07.38
Max.
temperature at
current fault
0.0°C
P17.13
Digital output
terminals state
0
7.13 Multi-step speed running
Set the parameters when the inverter carries out multi-step speed running. Goodrive300-19 series
inverters can set 16 stages speed which can be selected by the combination code of multi-step speed
terminals 1~4. They correspond to multi-step speed 0 to 15.
