Goodrive300-19 series open loop vector inverter special for hosit Basic operation instruction
-151-
14: Shift between combination setting and A setting
15: Shift between combination setting and B setting
P08.42
Keypad data
control
LED ones: frequency enable selection
0: Both ∧/∨ key and digital potentiometer adjustment
are valid
1: Only ∧/∨ key adjustment is valid
2: Only digital potentiometer adjustment is valid
3: Neither ∧/∨ key nor digital potentiometer adjustment
is valid
LED tens: frequency control selection
0: Only valid when P00.06=0 or P00.07=0
1: Valid for all frequency setting manner
2: Invalid for multi-step speed when multi-step speed has
the priority
LED hundreds: action selection during stopping
0: Setting is valid
1: Valid during running, clear after stopping
2: Valid during running, clear after receiving the stop
command
LED thousands: ∧/∨ key and digital potentiometer
integral function
0: The integral function is valid
1: The integral function is invalid
0x0000
P08.43
Integral ratio of
keypad
potentiometer
0.01~10.00s
0.10s
P08.44
UP/DOWN
terminals
control
LED ones: frequency enable selection
0: UP/DOWN terminals setting is valid
1: UP/DOWN terminals setting is invalid
LED tens: frequency control selection
0: Only valid when P00.06=0 or P00.07=0
1: All frequency means are valid
2: When the multi-step speed has the priority, it is invalid to
the multi-step speed
LED hundreds: action selection during stopping
0x000
