Goodrive300-19 series open loop vector inverter special for hosit Basic operation instruction
-150-
P00.06
A frequency
command
0: Keypad
1: AI1
2: AI2
3: AI3
4: High-speed pulse HDI setting
5: Reserved
6: Multi-step speed running setting
7: Reserved
8: Modbus communication setting
9~12: Reserved
13: Hierarchical multi-step speed reference
0
P00.07
B frequency
command
0: Keypad
1: AI1
2: AI2
3: AI3
4: High-speed pulse HDI setting
5: Reserved
6: Multi-step speed running setting
7: Reserved
8: Modbus communication setting
9~12: Reserved
13: Hierarchical multi-step speed reference
2
P00.08
B frequency
command
reference
0: Maximum output frequency
1: A frequency command
0
P00.09
Combination
of setting
source
0: A
1: B
2: A+B
3: A-B
4: Max (A, B)
5: Min (A, B)
0
P05.01~
P05.09
Multi-function
digital input
terminal
10: Frequency setting increasing (UP)
11: Frequency setting decreasing (DOWN)
12: Frequency setting clear
13: Shift between A setting and B setting
