Current
reference
channel
P00.09
Multi-function terminal
function 13
Switch from A channel to
B channel
Multi-function terminal
function 14
Switch from
combination setting to
A channel
Multi-function terminal
function 15
Switch from
combination setting to
B channel
A
B
/
/
B
/
/
/
A+B
/
A
B
A-B
/
A
B
Max(A, B)
/
A
B
Min(A, B)
/
A
B
Note: "/" means the multi-function terminal is invalid under the current reference channel.
When select multi-function terminal UP (10) and DOWN (11) to set the internal assistant frequency,
P08.44 and P08.45 can be set to increase or decrease the set frequency quickly.
Sx
Sy
UP terminal
Function selection=10
DOWN terminal
Function selection=11
UP terminal state
DOWN terminal state
T
F
T
T
UP terminal frequency increasing integral rate P08.44
DOWN terminal frequency increasing integral rate P08.45
Relative parameters list:
Function
code
Name
Detailed instruction of parameters
Default
value
P00.03
Max. output
frequency
P00.04~400.00Hz
50.00Hz
P00.04
Upper limit of
running
frequency
P00.05~P00.03
50.00Hz
P00.05
Lower limit of
running
frequency
0.00Hz~P00.04
0.00Hz
