INVT Goodrive300-19 Series User Manual

Goodrive300-19 series open loop vector inverter special for hosit Basic operation instruction
-166-
35: Shift the motor 1 into motor 2
36: Shift the command to the keypad
37: Shift the command to the terminals
38: Shift the command to the communication
39: Pre-magnetized command
40~56: Reserved
57: Inverter enabling
58: Contactor feedback signal
59: Brake feedback signal
60: Joystick zero position signal
61: Hierarchical reference terminal 1
62: Hierarchical reference terminal 2
63: Hierarchical reference terminal 3
64: Hierarchical reference terminal 4
65: Hierarchical reference terminal 5
P05.10
Polarity
selection of
input terminals
0x000~0x1FF
0x000
P05.11
ON-OFF filter
time
0.000~1.000s
0.010s
P05.12
Virtual
terminals
setting
0: Virtual terminals are invalid
1: Modbus communication virtual terminals are valid
2~4: Reserved
0
P05.13
Terminals
control running
mode
0: 2-wire control 1
1: 2-wire control 2
2: 3-wire control 1
3: 3-wire control 2
0
P05.14
Switch-on
delay of S1
terminal
0.000~50.000s
0.000s
P05.15
Switch-off
delay of S1
terminal
0.000~50.000s
0.000s
P05.16
Switch-on
delay of S2
0.000~50.000s
0.000s
