INVT Goodrive300-19 Series User Manual

Goodrive300-19 series open loop vector inverter special for hosit Dimension drawings
-237-
B.4.2 Flange installation
Flange installation of 380V 1.5-30kW inverters
Flange installation of 380V 37-110kW inverters
Flange installation of 380V 132-200kW inverters
Installation dimension of 380V (unit: mm)
Model
W1
W2
W3
W4
H1
H2
H3
H4
D1
D2
Hole size
1.5kW~2.2kW
150
115
130
7.5
234
220
190
16.5
174.5
65.5
5
4kW~5.5kW
170
131
150
9.5
292
276
260
10
181
79.5
6
7.5kW~11kW
191
151
174
11.5
370
351
324
15
216.2
113
6
15kW~18.5kW
250
210
234
12
375
356
334
10
216
108
6
22kW~30kW
275
237
259
11
445
426
404
10
245
119
7
37kW~55kW
270
130
261
65.5
555
540
516
17
325
167
7
75kW~110kW
325
200
317
58.5
680
661
626
23
363
182
9.5
132kW~200kW
500
180
480
60
870
850
796
37
358
178.5
11
