INVT Goodrive300-19 Series User Manual

Goodrive300-19 series open loop vector inverter special for hosit Peripherial options and parts
-248-
Character
designation
Detailed instruction
A
FLT: inverter filter series
B
Filter type
P: power supply filter
L: output filter
C
Voltage degree
04: 3PH 380V AC
D
3 bit rated current code, “015” means 15A
E
Filter performance
L: Common type
H: High performance type
F
Utilization environment of the filters
A: the first envirtonment (IEC61800-3:2004) category C1 (EN 61800-3:2004)
B: the first envirtonment (IEC61800-3:2004) category C2 (EN 61800-3:2004)
C: the second envirtonment (IEC61800-3:2004) category C3 (EN 61800-3:
2004)
C.7.2 AC 3PH 380V(-15%)~440V(+10%)
Inverter model
Input filter
Output filter
GD300-19-1R5G-4
FLT-P04006L-B
FLT-L04006L-B
GD300-19-2R2G-4
GD300-19-004G-4
FLT-P04016L-B
FLT-L04016L-B
GD300-19-5R5G-4
GD300-19-7R5G-4
FLT-P04032L-B
FLT-L04032L-B
GD300-19-011G-4
GD300-19-015G-4
FLT-P04045L-B
FLT-L04045L-B
GD300-19-018G-4
GD300-19-022G-4
FLT-P04065L-B
FLT-L04065L-B
GD300-19-030G-4
GD300-19-037G-4
FLT-P04100L-B
FLT-L04100L-B
GD300-19-045G-4
GD300-19-055G-4
FLT-P04150L-B
FLT-L04150L-B
GD300-19-075G-4
GD300-19-090G-4
FLT-P04240L-B
FLT-L04240L-B
GD300-19-110G-4
