INVT Goodrive35 Series User Manual

Goodrive35 Series Closed-loop Vector Control VFD Basic operation instruction
138
Function
code
Name
Detailed instruction of parameters
Default
value
3: Static autotuning 2 (autotune part parameters)
P02.00
Motor type 1
0: Asynchronous motor
1: Synchronous motor
1
P02.01
Rated power of
asynchronous motor 1
0.1–3000.0 kW
Depend on
model
P02.02
Rated frequency of
asynchronous motor 1
0.01 Hz–P00.03 (max. output frequency)
50.00 Hz
P02.03
Rated speed of
asynchronous motor 1
1–36000 rpm
Depend on
model
P02.04
Rated voltage of
asynchronous motor 1
0–1200 V
Depend on
model
P02.05
Rated current of
asynchronous motor 1
0.8–6000.0 A
Depend on
model
P02.15
Rated power of
synchronous motor 1
0.1–3000.0 kW
Depend on
model
P02.16
Rated frequency of
synchronous motor 1
0.01 Hz–P00.03 (max. output frequency)
50.00 Hz
P02.17
Number of poles pairs
for synchronous motor 1
1–128
2
P02.18
Rated voltage of
synchronous motor 1
0–1200 V
Depend on
model
P02.19
Rated current of
synchronous motor 1
0.8–6000.0 A
Depend on
model
P05.01–P
05.09
Multi-function digital
input terminals
(S1–S8,HDI) function
selection
36: Shift the command to keypad
37: Shift the command to terminals
38: Shift the command to communication
P07.01
Parameter copy
The function code determines the manner of
parameters copy.
0: No operation
1: Upload the local function parameter to the
keypad
2: Download the keypad function parameter to
local address (including the motor parameters)
3: Download the keypad function parameter to
local address (excluding the motor parameter of
P02 and P12 group)
0
