INVT Goodrive35 Series User Manual

Goodrive35 Series Closed-loop Vector Control VFD Dimension drawings
264
C.4.2 Flange installation (unit: mm)
Figure C-7 Flange installation of 380 V 1.5-30 kW VFDs
Model
W1
W2
W3 W4 H1 H2
H3
H4
D1
D2
Installation
hole
Weight
(kg)
1.5 kW–2.2 kW
150
115
130 7.5 234 220
190
16.5
174.5
65.5
5
2
4 kW–5.5 kW
170
131
150 9.5 292 276
260
10
181
79.5
6
3.5
7.5 kW–11 kW
191
151
174 11.5 370 351
324
15
216.2
113
6
6
15 kW–18.5 kW
250
210
234 12 375 356
334
10
216
108
6
7.8
22 kW–30 kW
275
237
259
11
445
426
404
10
245
119
7
9.5
Figure C-8 Flange installation of 380 V 37-110 kW VFDs
