Goodrive35 Series Closed-loop Vector Control VFD Basic operation instruction
156
Detailed instruction of parameters
Rotor resistor of asynchronous
motor 2
Leakage inductance of
asynchronous motor 2
Mutual inductance of
asynchronous motor 2
Non-load current of
asynchronous motor 2
Rated power of synchronous
motor 2
Rated frequency of synchronous
motor 2
0.01 Hz–P00.03 (max. output
frequency)
Number of poles pairs for
synchronous motor 2
Rated voltage of synchronous
motor 2
Rated current of synchronous
motor 2
Stator resistor of synchronous
motor 2
Direct axis inductance of
synchronous motor 2
Quadrature axis inductance of
synchronous motor 2
Back EMF constant of
synchronous motor 2
7.7 Start-up and stop control
The start-up and stop control of the VFD includes three states: start after the running command during
normal powering on, start after the restarting function becomes valid during normal powering on and
start after the automatic fault reset.
There are three starting modes for the VFD: start from the starting frequency directly, start after the
AC brake and start after the rotation speed tracking. The user can select according to different
situations to meet their needs.
For the load with big inertia, especially in the cases where the reverse rotation may occur, it is better
to select starting after DC brake and then starting after rotation speed tracking.
Note: It is recommended to use the direct starting to drive synchronous motor.
