INVT Goodrive35 Series User Manual

Goodrive35 Series Closed-loop Vector Control VFD Product overview
12
Model
Output
power (kW)
Input current
(A)
Output
current (A)
Carrier
frequency (kHz)
GD35-030G-4-C1/D1/H1/H2/S1
30
70
60
1–15 (4)
GD35-037G-4-C1/D1/H1/S1
37
80
75
1–15 (4)
GD35-045G-4-C1/D1/H1/S1
45
94
92
1–15 (4)
GD35-055G-4-C1/D1/H1/S1
55
128
115
1–15 (4)
GD35-075G-4-C1/D1/H1/S1
75
160
150
1–15 (2)
GD35-090G-4-C1/D1/H1/S1
90
190
180
1–15 (2)
GD35-110G-4-C1/D1/H1/S1
110
225
215
1–15 (2)
GD35-132G-4-C1/D1/H1/S1
132
265
260
1–15 (2)
GD35-160G-4-C1/D1/H1/S1
160
310
305
1–15 (2)
GD35-185G-4-C1/D1/H1/S1
185
345
340
1–15 (2)
GD35-200G-4-C1/D1/H1/S1
200
385
380
1–15 (2)
GD35-220G-4-C1/D1/H1/S1
220
430
425
1–15 (2)
GD35-250G-4-C1/D1/H1/S1
250
460
480
1–15 (2)
GD35-280G-4-C1/D1/H1/S1
280
500
530
1–15 (2)
GD35-315G-4-C1/D1/H1/S1
315
580
600
1–15 (2)
Note:
1. The input current of VFDs 1.5–315 kW is detected when the input voltage is 380 V and there is no
DC reactors and input/output reactors.
2. The rated output current is defined when the output voltage is 380 V.
3. The output current cannot exceed the rated output current and the output power cannot exceed the
rated output power in the voltage range.
3.6.2 Rated value of AC 3PH 520 V (-15%)–690 V (+10%)
Model
Output
power (kW)
Input current
(A)
Output current
(A)
Carrier frequency
( kHz)
GD35-022G-6-C1/D1/H1
22
35
27
1–15 (4)
GD35-030G-6-C1/D1/H1
30
40
34
1–15 (4)
GD35-037G-6-C1/D1/H1
37
47
42
1–15 (4)
GD35-045G-6-C1/D1/H1
45
52
54
1–15 (4)
GD35-055G-6-C1/D1/H1
55
65
62
1–15 (4)
GD35-075G-6-C1/D1/H1
75
85
86
1–15 (2)
GD35-090G-6-C1/D1/H1
90
95
95
1–15 (2)
GD35-110G-6-C1/D1/H1
110
118
131
1–15 (2)
GD35-132G-6-C1/D1/H1
132
145
147
1–15 (2)
GD35-160G-6-C1/D1/H1
160
165
163
1–15 (2)
GD35-185G-6-C1/D1/H1
185
190
198
1–15 (2)
GD35-200G-6-C1/D1/H1
200
210
216
1–15 (2)
