INVT Goodrive35 Series User Manual

Goodrive35 Series Closed-loop Vector Control VFD Basic operation instruction
169
Function
code
Name
Detailed instruction of parameters
Default
value
P06.18
Corresponding AO1 output
of lower limit
0.00 V–10.00 V
0.00 V
P06.19
Upper output limit of AO1
P06.13–300.0%
100.0%
P06.20
Corresponding AO1 output
of upper limit
0.00 V–10.00 V
10.00 V
P06.21
AO1 output filter time
0.000 s–10.000 s
0.000 s
P06.22
Lower output limit of AO2
-300.0%–P06.24
0.0%
P06.23
Corresponding AO2 output
of lower limit
0.00 V–10.00 V
0.00 V
P06.24
Upper output limit of AO2
P06.18–300.0%
100.0%
P06.25
The corresponding AO2
output of upper limit
0.00 V–10.00 V
10.00 V
P06.26
AO2 output filter time
0.000 s–10.000 s
0.000 s
P06.27
Lower output limit of HDO
-300.0%–P06.29
0.0%
P06.28
Corresponding HDO
output of lower limit
0.00–50.00 kHz
0.0 kHz
P06.29
Upper output limit of HDO
P06.23–300.0%
100.0%
P06.30
Corresponding HDO
output of upper limit
0.00–50.00 kHz
50.00 kHz
P06.31
HDO output filter time
0.000 s–10.000 s
0.000 s
7.11 Digital input
Goodrive35 series VFDs have 8 programmable digital input terminals and 1 open circuit electrode
output terminal in the standard configuration. All functions of the digital input terminals are
programmable by the function codes. Open collector pole input can be selected into high speed pulse
input terminal or common switch input terminal by function code. When selected into HDI, the user
can select HDI high speed pulse input as frequency reference, counting input or length pulse input by
setting.
