INVT Goodrive35 Series User Manual

Goodrive35 Series Closed-loop Vector Control VFD Basic operation instruction
155
Function
code
Name
Detailed instruction of parameters
Default
value
P02.10
Non-load current of
asynchronous motor 1
0.1–6553.5 A
Depend on
model
P02.15
Rated power of synchronous
motor 1
0.1–3000.0 kW
Depend on
model
P02.16
Rated frequency of synchronous
motor 1
0.01 Hz–P00.03 (max. output
frequency)
50.00 Hz
P02.17
Number of poles pairs for
synchronous motor 1
1–128
2
P02.18
Rated voltage of synchronous
motor 1
0–1200 V
Depend on
model
P02.19
Rated current of synchronous
motor 1
0.8–6000.0 A
Depend on
model
P02.20
Stator resistor of synchronous
motor 1
0.001–65.535 Ω
Depend on
model
P02.21
Direct axis inductance of
synchronous motor 1
0.01–655.35 mH
Depend on
model
P02.22
Quadrature axis inductance of
synchronous motor 1
0.01–655.35 mH
Depend on
model
P02.23
Back EMF constant of
synchronous motor 1
0–10000
300
P05.01–P
05.09
Multi-function digital input
terminals
(S1–S8, HDI) function selection
35: Shift from motor 1 to motor 2
P08.31
Motor shifting
0: Terminal shifting;
1: Modbus communication shifting
2: PROFIBUS/CANopen
communication shifting
0
P12.00
Motor 2
0: Asynchronous motor
1: Synchronous motor
1
P12.01
Rated power of asynchronous
motor 2
0.1–3000.0 kW
Depend on
model
P12.02
Rated frequency of
asynchronous motor 2
0.01 Hz–P00.03 (max. output
frequency)
50.00 Hz
P12.03
Rated speed of asynchronous
motor 2
1–36000 rpm
Depend on
model
P12.04
Rated voltage of asynchronous
motor 2
0–1200 V
Depend on
model
P12.05
Rated current of asynchronous
motor 2
0.8–6000.0 A
Depend on
model
P12.06
Stator resistor of asynchronous
motor 2
0.001–65.535 Ω
Depend on
model
