INVT SV-DA200 User Manual

SV-DA200 series AC servo drives Faults and solutions
‐120‐
PTP control trigger TRIG 0x11B 0x01B P
Vibration control switching input VS-SEL 0x11C 0x01C P F
Fast stop Q-STOP 0x11D 0x01D P S T F
PTP control stop PTP-ST 0x11E 0x01E P
Absolute position clearing PCLR 0x11F 0x01F P
Internal position command 5 POS5 0x120 0x020 P
Internal position command 6 POS6 0x121 0x021 P
Internal position command 7 POS7 0x122 0x022 P
Forward jogging FJOG 0x123 0x023 P
Reverse jogging RJOG 0x124 0x024 P
High/low speed switching of
jogging
JOGC 0x125 0x025 P
(Reserved) / 0x126 0x026
(Reserved) / 0x127 0x027
(Reserved) / 0x128 0x028
(Reserved) / 0x129 0x029
(Reserved) / 0x12A 0x02A
Terminal JOG enabling DJOG 0x12C 0x02C P
Gantry synchronization input clear GIN 0x12D 0x02D P
Master gantry synchronization
alignment sensor
GSM 0x12E 0x02E P
Slave gantry synchronization
alignment sensor
GSS 0x12F 0x02F P
Dynamic braking relay feedback DBS 0x130 0x030 P S T F
Manual and automatic switching of
turret
DAT 0x131 0x031 P
Forward jogging of turret DFJ 0x132 0x032 P
Reverse jogging of turret DRJ 0x133 0x033 P
Note: The default value is the function selection corresponding to the position mode.
P3.00
1
Data size 16bit Data format HEX
Modbus address 1600,1601 CANopen address 0x2300, 0x00
P3.01
1
Input configuration of digital 2
Setting range Default Unit Available mode
0x000~0x133 0x00D - P S T F
P3.02
1
Input configuration of digital 3 Setting range Default Unit Available mode
0x000~0x133 0x004 - P S T F
P3.03
1
Input configuration of digital 4 Setting range Default Unit Available mode
0x000~0x133 0x016 - P S T F
P3.04
1
Input configuration of digital 5 Setting range Default Unit Available mode
0x000~0x133 0x019 - P S T F
P3.05
1
Input configuration of digital 6 Setting range Default Unit Available mode
