SV-DA200 series AC servo drives Faults and solutions
‐155‐
function.
128-2047 Invalid
2048 Forced to stop
Example: Writing PTP signal 3 means to trigger the PTP program 3.
P5.20*
Data size 16bit Data format DEC
Modbus address 2040,2041 CANopen address 0x2514,0x00
P5.21 00 target speed
Setting range Default Unit Available mode
0~6000 20 r/min P
P5.22 01 target speed
Setting range Default Unit Available mode
0~6000 50 r/min P
P5.23 02 target speed
Setting range Default Unit Available mode
0~6000 100 r/min P
P5.24 03 target speed
Setting range Default Unit Available mode
0~6000 200 r/min P
P5.25 04 target speed
Setting range Default Unit Available mode
0~6000 300 r/min P
P5.26 05 target speed
Setting range Default Unit Available mode
0~6000 500 r/min P
P5.27 06 target speed
Setting range Default Unit Available mode
0~6000 600 r/min P
P5.28 07 target speed
Setting range Default Unit Available mode
0~6000 800 r/min P
P5.29 08 target speed
Setting range Default Unit Available mode
0~6000 1000 r/min P
P5.30 09 target speed
Setting range Default Unit Available mode
0~6000 1300 r/min P
P5.31 10 target speed
Setting range Default Unit Available mode
0~6000 1500 r/min P
P5.32 11 target speed
Setting range Default Unit Available mode
0~6000 1800 r/min P
P5.33 12 target speed
Setting range Default Unit Available mode
0~6000 2000 r/min P
P5.34 13 target speed
Setting range Default Unit Available mode
0~6000 2300 r/min P
P5.35 14 target speed
Setting range Default Unit Available mode
0~6000 2500 r/min P
P5.36 15 target speed
Setting range Default Unit Available mode
0~6000 3000 r/min P
These parameters are used to set the target speed of each step bit.
