INVT SV-DA200 User Manual

SV-DA200 series AC servo drives Communication
‐233‐
Connection Operation Instruction
Micro USB wire
Standard Micro-USB wire
After power on, the USB wire
can connect with the computer
and to install the designated
drive program
8.5.5 Software installation and operation
(The software installation program INVT ServoPlorer V4.0 can be downloaded from the website of our
company: http://www.invt-tech.com/products_187_12.html) During installation, automatically detect
whether the user computer needs necessary plug-ins and pop up corresponding prompt messages.
Ensure the software and hardware configuration of the computer meets the requirements in 8.5.2 and
8.5.3 before using.
The USB device drive program of the drive is in the drive folder in the directory of software installation
(path: ..\ServoPlorer\Drive\USB drive\). If necessary, the operation procedures for installing drive
program in manual are as follows: My computer → Hardware device manager → Update drive
program → Open the folder where drive program is → Select the folder labeled in the red box below
When starting ServoPlorer software, double click ServoPlorer.exe in the directory of software
installation as follows:
After starting the program, pop up a start-up interface and then the main interface of the software.
