INVT SV-DA200 User Manual

SV-DA200 series AC servo drives Control mode applications
‐53‐
setting range of P3.59; there is 5% detection retention.
Signal name Sign Function number Available mode
PTP arrival PTPF 0x16 P
This function is output PTP arrival signal.
Signal name Sign Function number Available mode
PTP output 1 PTPO1 0x17 P
This function is output PTP output 1 signal.
Signal name Sign Function number Available mode
PTP output 2 PTPO2 0x18 P
This function is output PTP output 2 signal.
Signal name Sign Function number Available mode
PTP output 3 PTPO3 0x19 P
This function is output PTP output 3 signal.
Signal name Sign Function number Available mode
PTP output 4 PTPO4 0x1A P
This function is output PTP output 4 signal.
Signal name Sign Function number Available mode
PTP output 5 PTPO5 0x1B P
This function is output PTP output 5 signal.
Signal name Sign Function number Available mode
PTP output 6 PTPO6 0x1C P
This function is output PTP output 6 signal.
Signal name Sign Function number Available mode
PTP output 7 PTPO7 0x1D P
This function is output PTP output 7 signal.
Signal name Sign Function number Available mode
Gantry synchronization output clear GSC 0x1E P
This function is to output the clearance signal of gantry synchronization
Signal name Sign Function number Available mode
Dynamic brake relay control DBRC 0x1F P S T F
This function is output dynamic brake relay control signal.
4.4.5 Pulse input signals and functions
Sign Pin no. Name Function
OCP 38 Position command pulse  In the position control mode, act as the position
