Iseki TH4330 - General Dimensions and Load Ratings

TH4330,4290,4260
84
GENERAL DIMENSIONS (Hydrostatic Transmission)
A1
A2
B
C D
- -
-
Reference
Height of
Steering Wheel
Overall Height
ROPS
Overall Width
Overall Length
Wheelbase
Min. Ground
Clearance
Turning diameter
w/o brake
Weight
TH4260
Hydrostatic
Turf Tire
Front: 24 x 8.50 - 12
Rear: 315/80D - 16
1370 mm
2350 mm 1260 mm
1390 mm
1120 mm
1260 mm 1390 mm
1120 mm
1260 mm
1390 mm
1120 mm
2925 mm
1665 mm
200 mm
5600 mm
960 kg
985 kg
965 kg 970 kg 995 kg 975 kg 980 kg 1005 kg 985 kg
Wide Turf Tire
Front: 26 x 12.00 - 12
Rear: 13.6 - 16
1425 mm 2400 mm
250 mm
Agri. Tire
Front: 6 - 14
Rear: 9.5 - 22
1420 mm 2395 mm
245 mm
TH4290
Turf Tire
Front: 24 x 8.50 - 12
Rear: 315/80D - 16
1370 mm
2350 mm
200 mm
Wide Turf Tire
Front: 26 x 12.00 - 12
Rear: 13.6 - 16
1425 mm
2400 mm
250 mm
Agri. Tire
Front: 6 - 14
Rear: 9.5 - 22
1420 mm
2395 mm
245 mm
TH4330
Turf Tire
Front: 24 x 8.50 - 12
Rear: 315/80D - 16
1370 mm 2350 mm
200 mm
Wide Turf Tire
Front: 26 x 12.00 - 12
Rear: 13.6 - 16
1425 mm
2400 mm
250 mm
Agri. Tire
Front: 6 - 14
Rear: 9.5 - 22
1420 mm
2395 mm
245 mm
Front
Rear
Turf Tire Wide Turf Tire
Agri. Tire
Tire size
24 x 8.50 - 12
315/80D - 16
Dimension
diameter x width
614 mm x 216 mm
910 mm x 273 mm
Tire size
26 x 12.00 - 12
13.6 - 16
Dimension
diameter x width
660 mm x 310 mm
1009 mm x 355 mm
Tire size
6 - 14
12.4 - 16
Dimension
diameter x width
653 mm x 155 mm
955 mm x 284 mm
