Iseo X1R Smart User Manual

18
Technical data
Features
Description
RFID Reader
 Multistandard 13,56 Mhz
 ISO14443A/ ISO14443B (Mifare Classic/Plus/DesFire).
Bluetooth 4.0 Module
 2,4GHz Radio Board
Power Supply
 Power supply unit 8-30Vdc, P = 30W
 6 x 1,5V Alkaline Batteries “D” Type
 Door sensor contact
Optoisolated input
 8-30Vdc/ac
Output relay (contact resistive)
 Contact rating (resistive): 30Vdc/ac, 1A MAX
Battery life (valid only for battery
powered version)
 Up to 20.000 opening (*)
 4 levels battery charge detection by the Argo App.
(*) Depending on usage, environment, options.
Software
 Argo app available for Android and iOS.
 Automatic software upgrade: when an update is available your
phone notifies you and the new software will be automatically
installed in the lock from your phone.
Version
 Standard
 Single Action
Mechanical dimensions
 Handle follower: 8mm
 Backset: 63mm
 Centre distance: 85mm
Functional modes
 2 functional modes to be set by the end user by the Argo App.
Opening commands
 Bluetooth 4.0 by the Argo App
 RFID reader
 External keyboard
 Internal control module
 Remote opening command
Finishes (faceplates)
 Inox
 Polished Inox
 Satin brass
 Polished brass
Mechanical lock case compatibility
 Euro profile cylinder hole (EN1303, DIN18252)
Environmental characteristics
 Operating temperature: from -20°C to +70°C
 Storage temperature: from -20°C to +70°C
 H.R. Max. 95% without condensing.
Overview

Iseo X1R Smart Specifications

General

Brand	Iseo
Model	X1R Smart
Category	Locks
Language	English
