Light & acoustic signal
Meaning
Notes
Battery low.
During door opening or closing.
Battery very low.
Before door opening or closing. Opening
and closing delayed.
Battery empty.
No opening or closing.
Wiring specifications
In the next table you can find the wiring specifications in relation to the power supply voltage and
the distance between power supply and lock.
Wiring
Lock and power
supply maximum
distance (mt)
Minimum power supply
(Vdc)
Minimum wire gauge (mm
2
) in
relation to the power supply
External power supply
2mt
10
0,75
5mt
12
0,75
10mt
12
1
20mt
12
1,5
Remote opening
command
100mt
9
0,3
Door status relay
Wiring specifications depends on relay characteristics (see paragraph Technical
Data), and on the operating characteristics of the circuit or system controlled by
the relay.
Appendix
For the complete Light and acoustic signal list, related to the Argo app, and in common
to all the other Smart series devices, see the Argo User Manual, available at link:
https://app.iseo.com
