Chapter 1 BEFORE USE
1-8 UNI-7 User’s Manual
6.
Push the cassette straight into the main body to return to its original position.


yBefore inserting the cassette unit into the main body, ensure that nothing sticks to the
magnet on the bottom of the cassette unit.
yPush the cassette slowly into the main body so as not to get your fingers caught.
7.
For labels, press the [FEED] key on the key sheet to issue a label.
At this time, confirm that the label is completely peeled off.


Confirm that the backing paper is wound up smoothly. If the backing paper is wound up
diagonally, check that the label is set correctly.


ISHIDA UNI-7 Specifications

General

Use conditions	Temperature: -5 to 35°C Humidity: 30 to 85%, Non condensing.
Power supply:	AC100 – 240V, 50 / 60Hz
Power consumption	1.0A/0.5A
Weighing capacity Scale interval	15 kg: 0 to 6/0.002 kg, 6 to 15/0.005 kg 30 lb: 0 to 15/0.005 lb, 15 to 30/0.01 lb
Weighting accuracy	1/3000
Printing method	Direct thermal method
Printing speed	100mm/second, 120mm/second Note: The printing speed may vary according to label conditions.
Printing effective size	56mm
Label size	Label width: 30mm to 60mm Label length: 20mm to 150mm
Operator/Customer display	7.0 inch color liquid crystal with back light, 480 X 234dots
Thermal head	2 inches (448dots) and 8 dots/mm
Number of label cassettes	7 cassettes
Program store medium	Flash ROM (32M bytes)
Input/Output	LAN 1 channel USB 1 channel CF 1 channel Drawer 2 channels
