ISHIDA UNI-7 User Manual

Chapter 1 BEFORE USE

1.9 STARTING PROCEDURES

1.9.1 TURNING ON THE POWER

1.
Push down the "I” side of the Power Switch to turn on the power.
2.
The Time Check screen appears.
Then, check that displayed date and time agree with current date and time, and press the
[ENTER] button on the screen to proceed to the next step.
Note: Refer to “Time/Date Set” menu in Adjust Mode when changing the date or time.
3.
After a while, the initial screen appears.
21-JUN-2007
11:13:38

1-14 UNI-7 User’s Manual

ISHIDA UNI-7 Specifications

General

Use conditions	Temperature: -5 to 35°C Humidity: 30 to 85%, Non condensing.
Power supply:	AC100 – 240V, 50 / 60Hz
Power consumption	1.0A/0.5A
Weighing capacity Scale interval	15 kg: 0 to 6/0.002 kg, 6 to 15/0.005 kg 30 lb: 0 to 15/0.005 lb, 15 to 30/0.01 lb
Weighting accuracy	1/3000
Printing method	Direct thermal method
Printing speed	100mm/second, 120mm/second Note: The printing speed may vary according to label conditions.
Printing effective size	56mm
Label size	Label width: 30mm to 60mm Label length: 20mm to 150mm
Operator/Customer display	7.0 inch color liquid crystal with back light, 480 X 234dots
Thermal head	2 inches (448dots) and 8 dots/mm
Number of label cassettes	7 cassettes
Program store medium	Flash ROM (32M bytes)
Input/Output	LAN 1 channel USB 1 channel CF 1 channel Drawer 2 channels
