iSMA MINI Series - 6.5 Registers 40156-40167

MINI and MIX Series I/O modules/Modbus
version 1.3 www.gc5.pl Page 58 / 73
Modbus
Addr
Dec
Addr
Hex
Addr
Register name
Access
Description
Memory
40141
140
0x8C
WATCHDOG TIME
Read &
Write
Memory
Time in second before watchdog reset
in case no transmission.
A value of 0 disables Watchdog.
The default value is 0s
40143
142
0x8E
DEFAULT STATE OF
DIGITAL OUTPUTS
Read &
Write
Memory
State of Digital Outputs assigned at the
start of the module and watchdog reset.
The default value is 0.
40144
143
0x8F
DEFAULT STATE OF
ANALOG OUTPUTS
(DIGITAL)
Read &
Write
Memory
State of Analog Outputs assigned at the
start of the module and watchdog reset.
The default value is 0.
40145
144
0x90
DEFAULT STATE OF
ANALOG OUTPUT 1
Read &
Write
Memory
In the registers is stored value that
appears at the Analog Output after
power on or watchdog reset.
The default value is 0.
40146
145
0x91
DEFAULT STATE OF
ANALOG OUTPUT 2
Read &
Write
Memory
40147
146
0x92
DEFAULT STATE OF
ANALOG OUTPUT 3
Read &
Write
Memory
40148
147
0x93
DEFAULT STATE OF
ANALOG OUTPUT 4
Read &
Write
Memory
40149
148
0x94
DEFAULT STATE OF
ANALOG OUTPUT 5
Read &
Write
Memory
40150
149
0x95
DEFAULT STATE OF
ANALOG OUTPUT 6
Read &
Write
Memory
40151
150
0x96
UNIVERSAL INPUT
CONFIGURATION 1
Read &
Write
Memory
Configuration of Universal Input and
type of temperature sensor.
The default value is 1.
Valu
e
Description / Sensor
0
Resistance
measurement off
1
10K3A1 NTC
2
10K4A1 NTC
3
10K NTC Carel
40152
151
0x97
UNIVERSAL INPUT
CONFIGURATION 2
Read &
Write
Memory
40153
152
0x98
UNIVERSAL INPUT
CONFIGURATION 3
Read &
Write
Memory
40154
153
0x99
UNIVERSAL INPUT
CONFIGURATION 4
Read &
Write
Memory
40155
154
0x9A
UNIVERSAL INPUT
Read &
