ENGINE ELECTRICAL 6D1 – 7
WARNING:
Never attach the end of the jumper cable directly to
the negative terminal of the dead battery.
5. Start the engine of the vehicle with the good battery.
Make sure that all unnecessary electrical accessories
have been turned "OFF".
6. Start the engine of the vehicle with the dead battery.
7. To remove the jumper cables, follow the above
directions in the reverse order.
Be sure to first disconnect the negative cable from the
vehicle with the discharged battery.
REMOVAL AND INSTALLATION OF THE
BATTERY
REMOVAL
1. All switches should be in the "OFF" position.
2. Disconnect the battery ground cable.
3. Disconnect the battery positive cable.
4. Disconnect the battery cable.
CAUTION:
It is important that the battery ground cable be
disconnected first.
Disconnecting the battery positive cable first can
result in a short circuit.
INSTALLATION
To install the battery, follow the removal procedure in the
reverse order, noting the following points:
1. Make sure that the rod is hooked on the body side.
MAIN DATA AND SPECIFICATIONS
Model (JIS) 115E41R-MF 130E41R-MF 95D31R-MF 80D26R-MF
Voltage (V)12121212
Cold-Cranking Performance (Amp) 651 799 622 582
Reserve Capacity (Min) 212 229 159 133
Load Test (Amp) 325 400 310 290
Fast Charge Maximum Amperage (Amp) 20 20 20 20
BCI Group No. - - 27 24
Overall Dimension L×W×H (mm) 410×178×213 410×178×213 - -
6D1-7-1.tif
