iSystem iC5000 User Manual

7
38-pin Mictor ARM ETM 16-bit D. Adapter
Ordering code
IC50115
This debug adapter is used to connect the iC5000 and the iC5700 BlueBox to the Cortex-A, the
Cortex-R, the ARM7 and the ARM9 based target. It’s used to connect to the embedded target
featuring a 38-pin Mictor target debug connector with the ARM ETMv1 or the ARM ETMv3
pinout.
The debug adapter connects to the BlueBox through the two ribbon cables and to the target
debug connector on the other side. Refer to the BlueBox User Manual for more details on
connecting the debug adapter.
The same debug adapter covers the ARM ETMv1 and the ARM ETMv3 pinout. The following
pinout is valid on the target side for the ARM ETMv1:
Signal direction
Signal
Pin
Pin
Signal
Signal direction
NC
1
2
NC
NC
3
4
NC
NC
5
6
TRACECLK
I
NC
7
8
NC
O
nSRST
9
10
NC
I
TDO
11
12
VTref
I
NC
13
14
NC
O
TCK
15
16
TRACEPKT[7]
I
O
TMS
17
18
TRACEPKT[6]
I
O
TDI
19
20
TRACEPKT[5]
I
O
nTRST
21
22
TRACEPKT[4]
I
I
TRACEPKT[15]
23
24
TRACEPKT[3]
I
I
TRACEPKT[14]
25
26
TRACEPKT[2]
I
I
TRACEPKT[13]
27
28
TRACEPKT[1]
I
I
TRACEPKT[12]
29
30
TRACEPKT[0]
I
I
TRACEPKT[11]
31
32
TRACESYNC
I
I
TRACEPKT[10]
33
34
PIPESTAT[2]
I
I
TRACEPKT[9]
35
36
PIPESTAT[1]
I
I
TRACEPKT[8]
37
38
PIPESTAT[0]
I
ETMv1 target pinout
