ITech IT6400 Series User Manual

Power Supply Function
Copyright © Itech Electronic Co., Ltd. 38
⚫ Variable output impedance
You can set the output impedance of the power supply. For the setting
range, see the specifications.
Source measurement functions
⚫ Voltage and current range
Model
Voltage Range
Current Range
IT6402
0-6V
0-2A
IT6411
0-15.05V
0-5.05A
IT6412
0-15.05V
0-5.05A
IT6431
0-15.05V
0-10.05A
IT6432
0-30.1V
0-5.05A
IT6433
0-60.1V
0-2.55A
IT6411S
0-15.05V
0-0.1A
IT6412S
0-15.05V
0-0.1A
IT6432S
0-30.1V
0-21mA
⚫ The current measurement is divided into High range and Auto range.
Take IT6411s as example, when Auto is configured, switch to Low mode
when current is lower than 100uA. The measurement precision is
0.05%+50nA and resolution ratio 1nA.
⚫ Measured parameters
Parameters
Parameter descriptions
Udc
Voltage average value [V]
Umax
The maximum voltage value [V]
Uhigh
The high voltage value [V]
Idc
Current average value [mA]
Imax
The maximum current value [mA]
Ihigh
The high current value [mA]
Ddc
DVM Measured Voltage average value [V]
P
Active power [W]
Urms
Voltage effective value [V]
Umin
The minimum voltage value [V]
Ulow
The low voltage value [V]
Irms
Current effective value [mA]
Imin
The minimum current value [mA]
Ilow
The low current value [mA]
Drms
DVM Measured Voltage effective value [V]
DVM Function
IT6400 series power supply is built in with a digital voltmeter (DVM), which can
be used for measuring external voltage.
4.2 Setting of Measurement Function and Interface
Display
The 4.3’’ colorful high-resolution TFT LCD of the IT6400 series power supply,
10 measurement parameters can be displayed in total, 4 of which are displayed
