Battery Simulation Function
Copyright © Itech Electronic Co., Ltd. 55
⚫ IT6402/IT6412/IT6412S
6.2 Battery Charging Function
The IT6400 series power supply is provided with battery charging function.
After selecting the battery charging mode (Charge), the “Charging voltage”
(Vset) and charging current (Iset) under the charging mode can be set. During
the charging, the voltage, current and charged capacity of the battery can be
observed.
Operation steps
1. Press the [Menu] key to enter the Menu Configuration page.
2. Select “Battery” to enter the Battery Simulation Function interface.
3. Press the right [Channel 1/2] soft key to select configuring channel CH2.
(Only IT6402/IT6412/IT6412S contain this step.)
To Next Page
