Basic Operation
Copyright © Itech Electronic Co., Ltd. 24
and the key, the power supply will shot the present screen and save it
to peripheral memory disk.
3.5 Save/Recall Operation
The power supply can save some common parameters in 50 groups of
nonvolatile memories (NVM) for convenient and fast access by the User,
comprising: voltage set value, current set value and resistance set value. The
soft keys [Save] and [Recall] or SCPI commands *SAV and *RCL can be used
for access operation in the save area.
Save operation:
1. Select “Menu > Source” to enter the Power Supply Function interface.
2. Press the [Channel(1/2)] soft key to select editing CH1. (Only
IT6402/IT6412/IT6412S contain this step.)
3. Set up parameters like voltage, current and resistance. For example, 3V,
0.5A and 0.2Ω (For details, refer to 4.3 Setting of Output Parameters).
4. Press the [Save] soft key to save the set parameters in the save position
displayed in present Save successively. In this case, the parameters are
saved in Save0.
5. Set up the parameters of Group 2, for example: 2V, 1A and 0.01Ω.
⚫ IT6411/IT6431/IT6432/IT6433/IT6411S/IT6432S
⚫ IT6402/IT6412/IT6412S
To Next Page
