Technical Specification
Copyright © Itech Electronic Co., Ltd. 79
Input Common-mode
voltage
< 50Vdc to ground
Common-mode voltage
rejection
≥ 80 dB
Input impedance
4.3MΩ ± 1%
(*1) Maximum error of OVP precision at power supply terminal under full load.
(*2) The output polarity is unchanged, the time that the power output value changes
from 10% to 90%.
(*3) The Minimum value of CC setting is 2mA.
(*4) The current readback accuracy of the 5mA Range is measured under
constant voltage mode.
(*5) Set output off.
Parameters
IT6411S
Rated values
(0 °C-40 °C)
Voltage
-15V-0V,0-15V
Current
±0.1 A
Power
1.5 W
Resistance
0-20 Ω
Load regulation
(of Output+Offset)
Voltage
≤0.01%+1mV
Current
≤0.05%+1mA
Line regulation
(of Output+Offset)
Voltage
≤0.02%+2mV
Current
≤0.05%+1mA
Setup resolution
Voltage
1mV
Current
10uA
OVP
1 mV
Resistance
10mΩ
Readback resolution
Voltage
1mV
Current
100mA Range
1uA
100uA Range
1nA (*4)
Setup accuracy
one year25°C)
(of Output+Offset)
Voltage
≤0.02%+3mV
Current
≤0.05%+50uA (*3)
OVP
0.5V (*1)
Resistance
≤0.1%+50mΩ
Readback accuracy
one year25°C)
(of Output+Offset)
Voltage
≤0.02%+2mV
100mA Range
≤0.05%+50uA
100uA Range
≤0.05%+50nA
Ripple
(20Hz -20MHz)
Voltage
≤ 3mVp-p / 1 mV rms
Current
≤2uArms
Setup Temp.coefficient
(of Output+Offset)/
Voltage
0.01%+0.2mV
Current
0.01%+2uA
OVP
0.1%+50mV
Resistance
0.02%+5mΩ
Readback
Temp.coefficient
(of Output+Offset)/
Voltage
0.01%+0.2mV
Current
100mA Range
0.015%+5uA
100uA Range
0.01%+10nA (*4)
Rise time No-load
Voltage
≤1mS (*2)
Rise time 150R load
Voltage
≤1mS (*2)
Fall time No-load
Voltage
≤1S (*2)
Fall time 150R load
Voltage
Change of setting value ≤1mS (*2)
Voltage
Set output off ≤0.5mS (*2)(*5)
