Remote Control
Copyright © Itech Electronic Co., Ltd. 9
Baudrate: 9600(4800, 9600, 19200, 38400, 57600, 115200). You could enter
the system menu to set the baudrate.
Data bit: 8
Stop bit: 1
Parity bit: (none, even, odd)
EVEN 8 data bits have even parity
ODD 8 data bits have odd parity
NONE 8 data bits have no parity
Native machine address: (0 ~30, factory default is 0)
1.6.2 USB Interface
Use a cable with two USB ports to connect power supply and PC. You can
program through USB interface to achieve all functions of power supply.
The functions of USB488 interface are as follows:
⚫ Interface is 488.2 USB488 interface
⚫ Receive the following request: REN_CONTROL, GO_TO_LOCAL, and
LOCAL_LOCKOUT
⚫ When the interface receives MsgID = TRIGGER USBTMC command, it will
transmit the TRIGGER command to the function layer.
The functions of power supply’s USB488 are as follows:
⚫ receive all SCPI commands
⚫ device is SR1 enabled
⚫ device is RL1 enabled
⚫ device is DT1 enabled
1.6.3 LAN Interface
Press (Shift) + (Menu) on the front panel together to access the
menu. Select LAN in the Communication from System and then configure
Gateway, IP, Mask and SocketPort in the LAN option.
Connect the LAN interface of power supply to the computer with a reticle
(crossed).
1.6.4 GPIB Interface
Use a IEEE488 bus to connect GPIB interfaces of power supply and PC.
Please ensure that the screws have been screwed down in order to have a full
