SeapiX – Operation Manual
SSD-C-1302 Ed. A – 01/2020 37
BATHY (tooltip: Surface)
It shows the bathymetry 2D layer.
ACQUISITION (tooltip: Start Seabed Data Record)
It stores seabed data (bathymetry, hardness) on a temporary basis.
BIOMASS (tooltip: Show Detections)
It shows the biomass 2D layer.
DISTRIBUTION (tooltip: Biomass Selection)
It shows the GBA biomass distribution.
STATISTIC (tooltip: Biomass Analyzer)
It opens the Biomass Analyzer window which shows the GBA class ratio
(%).
ALL (tooltip: ALL Fishes SV)
It shows the Scattered Volume (SV) - the fish shoal measurement - of all
types of fish.
FISH #1 (tooltip: PELAGIC Layer SV)
It shows the Scattered Volume (SV) - the fish shoal measurement – of
fish in the pelagic layer.
FISH #2 (tooltip: BOTTOM Layer SV)
It shows the Scattered Volume (SV) - the fish shoal measurement – of
fish in the bottom layer.
SETTINGS (tooltip: Settings...)
It is a shortcut which opens the Settings window.
