9
07610-003-78-18-N
SPECIFICATIONS
OPERATING PARAMETERS
Model Designation: 44" 66" 44" STEAM 66" STEAM
HOT WATER SANITIZING
Water Temperatures (°F):
Pre-Wash Temperature (recommended) N/A 110-140 N/A 110-140
Minimum Wash Temperature 160 160 160 160
Incoming Rinse Temperature 180 180 180 180
Incoming Water Temperature
12 kW Booster 140 140 N/A N/A
18 kW Booster 110 110 N/A N/A
No Booster 180 180 180 180
CHEMICAL SANITIZING
Water Temperatures (°F):
Pre-Wash Temperature (recommended) N/A 110-140 N/A 110-140
Minimum Wash Temperature 120 120 120 120
Minimum Rinse Temperature 120 120 120 120
Incoming Water Temperature
12 kW Booster 80 80 N/A N/A
18 kW Booster 50 50 N/A N/A
No Booster 120 120 120 120
Other Water Requirements:
Water Flow Pressure (PSI) 15 15 15 15
Flow Rate Minimum (GPM) 1.27 1.18 1.27 1.18
Water Line Size (NPT) 1/2" 1/2" 1/2" 1/2"
Drain Line Size (NPT) 1-1/2" 1-1/2" 1-1/2" 1-1/2"
Steam Requirements:
Steam Line for Wash Tank (NPT) N/A N/A 3/4" 3/4"
Steam Flow Pressure (PSI) N/A N/A 10-20 10-20
Consumption @ 15 PSI (lbs/hr) N/A N/A 60 60
NOTE: Always refer to the machine data plate for specic electrical and water requirements.
The material provided on this page is for reference only and may change without notice.
