8
07610-003-78-18-N
Machine Dimensions:
Height 72.5"
Width 48"
Depth 30.625"
Wall Clearance: 5'
Height 19.75"
Width 21"
Shipping Weight: 750lbs.
Shipping Size:
Length 77"
Depth 41"
Height 89"
Model Designation: 44" 66" 44" STEAM 66" STEAM
Operating Capacity:
Racks per Hour 218 218 218 218
Dishes per Hour 3488 3488 3488 3488
Glasses per Hour 7848 7848 7848 7848
Tank Capacity (Gallons):
Wash Tank 35.6 35.6 35.6 35.6
Pre-Wash Tank N/A 15.8 N/A 15.8
Electrical Loads (as applicable):
Wash Motor HP 3.0 3.0 3.0 3.0
Drive Motor HP 0.25 0.25 0.25 0.25
Pre-Wash Motor HP N/A 2.0 N/A 2.0
Wash Heater kW 15 or 18 18 N/A N/A
OPERATING PARAMETERS
SPECIFICATIONS
NOTE: Always refer to the machine data plate for specic electrical and water requirements.
The material provided on this page is for reference only and may change without notice.
