Jackson crew series - Temperature Board

73
07610-003-78-18-N
4
2
1
3
3
ITEM QTY DESCRIPTION PART NUMBER
1 1 Cyclic Temperature Board 06685-002-74-86
2 1 Gauge Cover, Red 05700-002-75-62
3 8 Nut, Thumb 6-32 Nylon 05310-002-83-12
4 1 Decal, Temperature Display 09905-003-78-29
5
2 (44")
3 (66")
RTD Temperature Probe (not shown) 06680-002-16-80
TEMPERATURE BOARD
SCHEMATICS
