28
07610-003-78-18-N
WASH MOTOR
VOLTAGE
PART NUMBER GE PART NUMBER
208 05945-003-76-29 MT03N
230 05945-003-76-29 MT03N
460 05945-003-76-27 MT03L
DRIVE MOTOR
VOLTAGE
PART NUMBER GE PART NUMBER
208 05945-003-76-23 MT03F
230 05945-003-76-23 MT03F
460 05945-003-76-21 MT03D
PRE-WASH MOTOR
VOLTAGE
PART NUMBER GE PART NUMBER
208 05945-003-76-28 MT03M
230 05945-003-76-28 MT03M
460 05945-003-76-26 MT03K
WASH MOTORS: Overloads are specied for 3-phase units only.
For GE brand MT03* series overloads, the process for setting is as follows:
• Determine the Full Load Amps for the wash motor.
• Set the overload at the closest setting without going over for the FLA of the motor.
• The overload already compensates for the FLA and will have a set point that is 125% of the FLA. (Example: Wash motor
is rated at 10.0 FLA on the data plate. The replacement MT03* overload will be set at 10.0. It will trip at 12.5 Amps.)
Blue selector switch should be
set to H for manual reset.
DRIVE MOTORS: Overloads are specied for 3-phase units only.
For GE brand MT03* series overloads, the process for setting is as follows:
• Determine the Full Load Amps for the drive motor.
• Set the overload at the closest setting without going over for the FLA of the motor.
• The overload already compensates for the FLA and will have a set point that is 125% of the FLA. (Example: Drive motor
is rated at 1.0 FLA on the data plate. The replacement MT03* overload will be set at 1.0. It will trip at 1.25 Amps.)
Blue selector switch should be
set to H for manual reset.
PRE-WASH MOTORS: Overloads are specied for 3-phase units only.
For GE brand MT03* series overloads, the process for setting is as follows:
• Determine the Full Load Amps for the pre-wash motor.
• Set the overload at the closest setting without going over for the FLA of the motor.
• The overload already compensates for the FLA and will have a set point that is 125% of the FLA. (Example: Pre-wash
motor is rated at 6.0 FLA on the data plate. The replacement MT03* overload will be set at 6.0. It will trip at 7.5 Amps.)
Blue selector switch should be
set to H for manual reset.
NOTE: Connections should be tightened to 7 in.-lbs.
OVERLOADS
PARTS
Imbalanced wild leg goes to L3.
