Page #36 background image
27
07610-003-78-18-N
ITEM QTY DESCRIPTION PART NUMBER
HC1 1
Contactor, 24VDC, 3 Pole (Used on 3-Phase Units)
Contactor, 24VDC, 4 Pole (Used on 1-Phase Units)
05945-003-75-02
05945-003-73-22
C1 1 Contactor, Drive Motor 05945-003-75-22
C2 1 Contactor, Wash Pump 05945-003-75-22
C3 1 Contactor, Pre-Wash Motor (66" Units Only) 05945-003-75-22
R1 1 Relay, Vent Fan 05945-003-76-34
R2 1 Relay, Rinse Signal 05945-003-76-34
R3 1 Relay, Temperature Board 05945-003-79-57
R4 1 Relay, Booster Heater (Optional) 05945-003-76-34
R5 1 Relay, Wash Tank Steam (Steam Units Only) 05945-003-76-34
R6 1 Relay, Photo Cell Table Limit (Optional) 05945-003-76-34
1MOL 1 Overload, Drive Motor (Used on 3-Phase Units) See Overload Page
2MOL 1 Overload, Wash Motor (Used on 3-Phase Units) See Overload Page
3MOL 1 Overload, Pre-Wash Motor (Used on 3-Phase 66" Units) See Overload Page
TB1 1 Terminal Board, Signal 05940-003-77-43
TB2 1 Terminal Board, DC 05940-003-77-65
TB3 1 Terminal Board, L1 05940-021-94-85
TB4 1 Terminal Board, L2 05940-021-94-85
TB5 1 Terminal Board, Blower 05940-021-70-74
1 1 Terminal Block 3 Pole 05940-011-48-27
2 1 Fan, 24VDC 05999-002-47-12
3 2 Fan Finger Guard 05999-003-12-92
4 1 Ground Lug 05940-200-76-00
5 1 Bracket, Fuse Strip 05700-002-42-03
6 1 Fuse Holder 05920-401-03-14
7 1 Fuse Holder, 6 Slot 05920-002-42-13
8 1 Holder, Bussman Fuse 05920-011-72-89
9 1
Fuse, 1.0 Amp (208V & 230V Units)
Fuse, 0.5 Amp (460V Units)
05920-002-67-23
05920-011-72-88
10 5 Relay Socket, 20A, 300V (Used for R1, R2, R4, R5 & R6) 05945-003-76-33
11 1 Relay Socket, 16A, 300V (Used for R3) 05945-003-79-58
12 1
Control Box Weldment (44" Units)
Control Box Weldment (66" Units) 05700-003-82-04
13 2 Screw, 10-32 x 1/2" Phillips Pan Head w/Washer 05305-002-32-37
PARTS
CONTROL BOX COMPONENTS
